1990 Inace Expedition 88

CONSTRUCTIONAluminum hull and superstructureDIMENSIONSGeneral  Length Overall (L.O.A.):      94.17 feet   (28.70 meters)    Length at Waterline (L.W.L.):  90.00 feet  (27.00 meters)    Beam (molded):            21.00 feet   ( 6.40 meters)    Draft (loaded):             5.50 feet   ( 1.68 meters)    Tonnage:                 109 gross  Displacement:             150,000 lbs.  Capacities  Fuel Capacity:             4,800 US Gallons  (18,168 liters)    Water Capacity:            1,000 US Gallons  ( 3,785 liters)  Black Water capacity:        800 US Gallons  ( 3,028 liters)    Grey Water capacity:        400 US Gallons  ( 1,514 liters)  Speed     Maximum:     12.5 knots  Cruising:      10.0 knotsMACHINERYMain EnginesEngine Type:  (2) Caterpillar C-9 @ 566 Hp each (2009)Transmission/Ratio:   2.179 : 1Propellers:  4-blade bronze 36”x24”Gearboxes for Main Engines: ZF 305-2A with trolling drives and DP dynamic positioning with joy stickDrive:  Direct driveGenerators & ElectricityOutput:  120/240V single phaseGenerators:  5 kW Onan @ 0.5 gallon per min (2006)15 kW Norpro @ 1 gallon per min (2009)30 kW Phasor @ 1.5 gallon per minute (2023) Batteries:• (8) 8D AGM• (4) Epoch Elite 100 ahr 48V, ABYC approved – new 2026• (2) Victron 10 kW inverters, ABYC approved – new 2026• (1) EGC Chargeverter Plus 5 kW, ABYC approved - new 2026 Inverters:  (2) Xantrex inverters, 3,000WAir ConditioningType:  AC 110/230V with heatOther MachineryTrim Tabs/Stabilizers:  ABT Trac (oversized 12 square feet) with at rest featureBow Thruster:  Hydraulic with variable speedSteering System:  Hydraulic - hoses replaced 2024Fuel Separator & Filtration:  Installed 2023Sewage System:  (2) 400 gallons eachFresh Water System:  (1) 1,000 gallons (aluminum)Grey Water System:  (1) 300 gallons (aluminum)Water heater:  30 gallons - 2024Bilge Pumps: (6) sections of bilge – pumped by (2) 1.5 Hp 240V bilge pumps; manualBattery operated bilge pumps - Engine room & fuel rooms(5) sections – high water alarmsCOMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMSCommunication SystemsAIS:  Furuno Type AVHF:  West Marine upper helmICOM ICN 504 standard– lower helmShip’s computer: Networked Furuno MFD systemNavigation SystemsRadar:  Furuno MFD8 – upper helmFuruno MFD12 – lower stationMagnetic Compass:  5” – upper helm & lower stationAuto Pilot: Furuno – upper helm & lower stationDepth Sounders:  (6) Various – upper helm & lower stationMonitors:(2) Simrad displaysGPS:  Furuno MFD8 – upper helm(2) Furuno GP-31; Furuno MFD12 – lower stationWind/Speed Log:  Furuno MFD8 – upper helmFuruno MFD12 – lower helmNavigation Lights:  24V – deck levelSteaming light: 24V mastCompass light:  24V  Entertainment System:a.  Video Equipment  TV’s:  (3) TCL 42" flat screen(1) ONN 24" flat screenb.  Audio Equipment  Stereo’s:  Jensen AM/FM/CDGALLEY & LAUNDRY EQUIPMENTMain Galley EquipmentCooking Equipment:  Oven and induction stove top – 2022(1) microwaveRefrigeration/Freezer: Yes, with an ice makerLaundry Equipment  Main Laundry Equipment  GE washer and dryer; front loadTENDERS & TOYS Tenders:  Dinghy – custom 12’ aluminum with 20 Hp Mercury 4 cycle engine - 2023Other:  3-person hot tub - bow DECK EQUIPMENTAnchor Windlass System: Hydraulic IdealAnchors:  (1) custom stainless steel San Francisco style 205 lbs.Anchor Chain:  300’ chainAnchor light:  24V mastheadShaft Bearing:  Rubber Cutlass  Boat Crane and Davits:  Radar mast/davit combo 2,000# 12V DC batterySECURITY, FIRE FIGHTING & SAFETY EQUIPMENTFire Fighting EquipmentFire Control System:  (2) Auto Ansul Haylon with pull - 2023Fire Extinguishers:  (8) ABC handhelds all cabinsAlarms:  Siren cellular alarm system - 2022Safety EquipmentLife Rafts:  Viking 6 manLife Rings: Lifesling, RingEPIRBS:  (2) - 2023Flares:  YesMedical Equipment:  YesACCOMMODATIONS GENERAL  Starting from the stern, you enter the yacht via a built-in swim platform onto a half-deck with a hurricane-proof salon door leading to an airy salon and dining area with dayhead, furnished with freestanding pieces. Moving forward along the starboard passageway, you’ll find the galley, crew quarters, storage areas, and the bow thruster compartment. A staircase on the port side of the salon provides access to three guest cabins. The yacht also features a raised pilothouse and an expansive bridge, offering ample space for a tender. The Captain's cabin in the crew quarters was converted to storage; however, it can be converted back to a cabin.BROKER’S COMMENTS:Originally built as an offshore supply vessel, PIER PRESSURE underwent a significant conversion in 1990 to become a private yacht. She was refitted in 2009 with new CAT engines, hydraulic, stabalizers and a bow thruster. Since 2022, additional upgrades to her technology and galley & mechanical equipment have been done. The current owner spent years cruising around the world, benefiting from the vessel's trans-Atlantic capability. With over $2 million invested, this versatile yacht is ready for new adventures as a long-range explorer or a customized expedition vessel. There is ample space to easily convert the aft deck to accommodate large tenders, ATVs, trucks, or jet skis, offering endless possibilities for the next owner.

Hot water heater replaced 2024All steering hydraulic hoses replaced 2024Engine sea valves and basket strainers replaced 2024Engine / Fuel Room fixed Fire Extinguishers replaced, All handheld extinguishers replaced  202330 kW generator replaced 2023: Phasor (Kohler engine) Dinghy replaced 2023: custom 12ft aluminum, 20hp Mercury 4 cycle engineFuel Transfer filter system added 2023 (never had a dirty fuel emergency)Siren (brand) cellular alarm system installed (bilge, fire, location, shore power, battery voltages) 2022Complete paint, bulwark rails added  2022Galley Appliances, stone countertop, GFI outlets  2022Salon and stateroom renovations 2022Fresh/Grey/Black tank level gauges installed Battery-powered automatic bilge pumps added in Fuel and Engine roomsShorepower Ground Isolation addedRadar Arch replaced with Radar Mast / Davit combo (2000#) (12V DC, independent battery(2) Simrad Displays added for redundancy to the Furuno system in chart plotting, each with independent depth sounders Datamarine depth sounder replaced with Raymarine - 5 totalPower Isolation transformer addedAnchors replaced with one custom stainless San Francisco style (weight is marked on anchor)New Lithium DC system addition: (4) Epoch Elite 100 ahr 48V, (2) Victron 10 kW inverters, (1) EGC Chargeverter Plus 5 kW – ABYC approved 2026

The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated.
