2026 AvA Yachts KANDO 85 Explorer Superyacht

A true little ship, the Kando 85 boasts an imposing profile that includes an On-Deck Master, three cabins below and crew forward.Stepping aboard from a floating dock is onto the swim platform or via side deck gates from a fixed dock.The Aft Deck has built-in seating around a dining table. The Salon has built in furniture port and starboard with a free-standing dining table forward.Going forward to starboard is a Day Head followed by the full beam On-Deck Master Suite.Going forward from the port side is an enclosed Galley.From the Main Lobby a set of stairs leads forward to two Crew Cabins, a Head and Crew Mess/Galley.Another set of stairs leads to the main accommodation area with a full beam VIP cabin, a double cabin to starboard and to port a twin cabin that converts to a double.The upper deck has a centerline Helm in the Wheelhouse, built in seating port and starboard and a Day Head aft to port. Outside is a walk behind bar with 3 bar stools, a davit and plenty of room for an owner supplied tender. A gently sloped stainless ladder leads to the Aft Deck.

Displacement Hull FormUnsinkable Hull on Flooding Water in any CompartmentMinimum 2.10 m Free Height in Cabins,4x Control Stations including 2 Helm Bridges with Emergency Stop Buttons

Hull: High Tensile Marine Steel AH36Superstructure: Aluminum Alloy Almg 5083 H321Hardtop: Sandwich System Epoxy CompositeFresh Water System: Polypropylene PipesSanitary System: PVC PipesFuel System: Mild Steel PipesSea Water Cooling System: CuNiFe PipesFire Extinguishing System: Mapress System or equivalentBilge Suction System: Mapress System or equivalentTank Air Vent System: Mapress System or equivalentHydraulic System: Seamless Steel PipesStainless Steel Equipment: AISI316L unless otherwise specified

Main Engines: VOLVO-PENTA D13's2x 450 HP @2100 RPM Heavy Duty Marine Engines2x Gearbox: TWINDISK or ZFPropulsion System: Long Shaft & Fixed Blade PropellersAISI316L Stainless Steel Propeller ShaftsMax Speed: 11 Knots (95% Engine Load)Cruise Speed: 7-9 Knots (60% Engine Load)Provisional Fuel Consumption & Cruise Range Figures:30 lts/hr @ 8 kts / 6700 nm45 lts/hr @ 9 kts /5000 nm63 lts/hr @ 10 kts /4000 nm142 lts/hr @11 kts /2000 nm

2x Control Stations:1x Wheelhouse, Aft Mooring place2x Dual Electronic Main Engine Throttles: VOLVO-PENTA1x Steering Gear: HIDROMARIN or DATA:Electro-Hydraulic Steering Gear Pump Actuated CylindersManual Operation Ability on EmergencyIncorporated with Rudder Angle Indicator and Autopilot System2x Rudder Blades:2x Steel Constructed, Foil Shaped Rudder Blades316L S.S. Rudder Shaft1x Bow Thruster: SIDE POWERHydraulic Operated a Bow Thruster Actuated by Central Hydraulic Power Unit2x Anchor Winch:Electric operated and made of Stainless Steel AISI316L Anchor Winch with Joystick on Control StationsTwo, Polished Stainless Steel AISI316L Chain Locks 2x Mooring Capstans: HIDROMARIN or DATA:Electric Operated through Central Power UnitPolished Stainless Steel AISI316L & Raised Position with Foot Buttons2x Anchors: INHOUSE:Galvanized Steel, High Holding Type, Seated at Port and Starboard Side180 Kg eachChain:110m, Grade 2, 12.5 mm Galvanized Steel Chain for each Anchor Incorporated with a Digital Chain Meter goes through 2 x S.S. AISI304 Hawse PipesSea water Chain Wash System, drains overboard10x Bollards: INHOUSE:Highest Quality Polished Stainless Steel AISI316L, Welded to the Raised Deck Position4x Large Size at the Fore Deck, 2x Large Size at the aft Main Deck, 2x Small Size at the Middle Main Deck, 2x Small Size at the Swimming Platform

Fin Stabilizing System: SLEIPNER:Electric Operated, Zero Speed FunctionalityAir Conditioning System : WEBASTO :Chilled Water Compressor Unit, 380V AC, Heat & CoolFan Coils in each Guest Cabins, Salon and Crew QuartersFresh Air Make-up UnitVolumes to be Air Conditioned; Main Deck Salon, All Guest & Crew Cabins, Wheelhouse, Galley, Crew Mess, LazaretteAir-Conditioned Spaces are Mechanically VentilatedWastewater Treatment System::TECHICOMAR or EquivalentVacuum Toilet System: JETSElectricity Extract Fan Ventilation in ToiletsWater Maker: SEA RECOVERY or Equivalent300 lt/h Capacity, Self-FlushingDeck Tender Crane: OPACMARE or BESENZONI:Hydraulic Operated, 500Kg Capacity, With its Self-Hydraulic Power UnitWindow Wipers in Wheelhouse : SPEICHPassarella Gangway: INHOUSE:Hydraulic, Remote Controlled, Adequate Length, Solid & Portable HandrailsFuel Separator: ALFA LAVAL:MIB303Flexible Propulsion Shaft Coupling: CENTAShore Power Cable Handling & Storage System: GLENDENNINGEngine Room Ventilation Fans:Electric Driven & CentrifugalAutomatic Sliding, Salon Aft Doors:Highest Quality Polished Stainless Steel Framed Glass, Curved ShapeMain Deck Salon & Upper Deck Salon2xStarlink DishSatellite TV Antenna: INTELLIAN or KVH:1x 60cm Bowl, 1x 60cm Empty DomeInter Communication Phone System:All Cabins, Main Deck Salon, Upper Deck Salon, Wheelhouse, Galley, Crew Mess, Flybridge & Lazarette2x Led Search Lights:Electric Remote Control8x Led Underwater Lights:4x at the Transom, 4x at the Sides at the Aft SideTeak Deck Covering on Weather Exposed Decks:First Class Teak Wood, 12mm ThicknessTempered Deck House Window GlassesWeather Exposed Deck Furniture & CushionsSeating Groups on Flybridge, Seating Groups on Aft PoolHard Top & Radar MastMoulded GRP, Sandwich SystemVarious Bulwark & Handrails:Highest Quality Polished Stainless Steel, AISI316L & Carbon FibreGuard Rails on Aft Swimming Platform:Highest Quality Polished Stainless Steel, AISI316L, PortableAir Horn: KAHLENBERGNavigation Lights:Led Lights, According to COLREGEngine Room Heat & Fire Insulation: ROCKWOOLAccommodation Spaces Heat Insulation: GLASSWOOL or ROCKWOOL

Radar & GPS Systems: RAYMARINE or Equivalent:3x 19” Touch Screen Color Display2x Open Array Radar, 12Kw, 4KwAutopilot Module, GPS Module, Sonar ModuleAIS650Sailor 6222 VhfEcdis

Central Monitoring & Alarm System: PRAXIS:Touch Screen Display in Wheelhouse and Crew QuarterMonitoring of Tank Levels, Bilge Levels, Diesel Generators, Propulsion Engines, Main Switchboard Voltage (220VAC + 380VAC), Shore Power Voltage, Battery Levels & Navigation LightsCamera Monitoring System: HAIKON:5x 1080p IR, IP Cameras8 Channel HD Camera Recorder15” Led Display in Main Helm BridgeMagnetic Compass, Barometer, Hydrometer KitEngines & Generators Digital Monitoring Indicators:Shall also be Monitored in AMSTank Level Monitoring Indicators:Digital Indicators on Wheel ConsoleShall also be Monitored in AMSBilge Level Alarms:Visible & Audible AlarmsShall also be Monitored in AMS

Home Appliances for Galley: SIEMENS:1x Cooking Oven, 1x Microwave Oven, 1x Induction Electric Cooking Range, 1x Dishwasher, 1 x Sink Garbage Disposal Unit1x Full Height Inox Refrigerator, 1 x Hull Height Inox Freezer Home Appliances for Crew Mess: SIEMENS:1x Cooking Oven, 1x Microwave Oven, 1x Induction Electric Cooking Range, 1x Dishwasher, & 1x Inox Refrigerator2x Washing Machine, 1x Dryer, 1x Ironing Mangle in Laundry: SIEMENS1x Small Size Refrigerator in Flybridge Bar1x Wine Coolers1x Ice Cube MakersLED TV’s: SAMSUNG:55” Smart Flat UHD 4K in Main Deck Salon – Retractable55” Smart Flat UHD 4K in Owner’s Suite – Fixed on the Wall40” Smart Flat UHD 4K in each cabin – Fixed on the Wall40” Smart Flat UHD 4K in Crew Quarter – fixed on the wallHome Theatre Sound System in Main Deck SalonStereo System on Pool Deck & Flybridge

Cabins, Salon, Furniture & Decoration:Plywood FurnitureOwner’s Choice Veneer, Satin Varnish FinishingArtificial Ladder or Textile UpholsteryWooden/Carpet Floor in Cabins, Wooden/Carpet Floor in SalonCustom Size Spring BedsTextile Curtains Toilets / Bathrooms / Wet Areas:Artificial Granite Bench TopsPolycarbonate Shower CabinsCeramic & Mosaic Tile DecorationTowel Dryers HeatersUnderfloor Heating

Aft Pool Seating Area:Watertight Upholstery with SpongeFixed Wooden (Iroko) Table with Stainless Steel LegDeck Shower on Swimming PlatformFore Deck Area:3-4 persons JacuzziSunbathing Group Watertight Upholstery with Sponge Flybridge:Various Seating Groups & Watertight Upholstery with SpongeGrill & Bar House with Cool BoxSunbathing Area

Fireboy/Xintex or equivalentEPIRB + SART Emergency Beacons2x Viking Life rafts On the Flybridge DeckSmoke Detection & Fire Alarm System in Engine Room & Accommodation CompartmentsPortable Fire Extinguishers in All CabinsFire Blankets in Galley, Crew Lounge, Engine Room

Fresh Water System:Filling, supplying cold water and circulating hot water connected to the freshwater storage tank, water maker and water heater, equipped with LIVERANI or equivalent electric driven, Fresh Water Pressure Pumps and hot water circulation pumps, SS or Bronze ball valves. Hot water circulation pipelines are to be heat insulated. Capacity of the pumps as per calculations.Sanitary Drain & Discharge System:Drainage of wastewater to the storage tanks and discharge the wastewater tank to Shore Connection on the aft deck and Wastewater Treatment Unit, equipped with electric driven, macerator pumps, SS or Bronze ball valves Bilge Suction & Discharge System:Suction and discharge of bilge water from each of watertight compartment separately equipped with two electric driven self-priming, centrifugal, bronze pumps, SS or Bronze ball valvesWater level gauges are to be provided with audible and visible alarm on main helm bridge.Water Fire Extinguishing System & Nozzles:Supplying sea water from sea chests to deck fire nozzles to the fire chests equipped with electric driven, centrifugal, Bronze, emergency pump, SS or Bronze ball valvesFuel Filling & Supply & Transfer System:Filling fuel tanks and supplying fuel to the consumers and return lines to the tanks, transferring the fuel between storage tanks or outside shore connection by means of electricity driven fuel transfer pump and air ventilation of the fuel storage tanksDouble Racor or equivalent filters for each fuel consumer on fuel supply linesSea Water Cooling System:A Central CuNiFe pipe system connected to two bottom sea chests in engine room with SS or Bronze butterfly valves and sea water strainersEngines, generators and other consumers are to be cooled with sea water supply via branch lines connected to central sea water cooling pipe. Consumer’s connection are to be made with Neoprene flexible hosesHydraulic System:Central hydraulic system consists of a center power unit with electricity driven pump and PTO pumps on the main propulsion engines, seamless steel pipelines to operate bow thruster, anchor winches, capstans. Equipment is to be connected to the system with high pressure flexible hosesMain Engines & Generators Exhaust System:Water cooled, heat insulated Main Engines exhaust pipes made of mild steelMuffler Exhaust System for GensetsAir Conditioning System:Chilled water circulation to fan coils and water drain from fan coils to the tanks with polypropylene pipe lines. Chilled water circulation pipelines are to be heat insulated

Electricity Power Supply:24V DC loads to be supplied via dedicated battery banks and with own battery charger/supply units230V 1-phase & 400V 3-phases 50Hz AC Power Generation from Generators400V 3-phases AC Power Supply Shore Connection Battery Groups  : VICTRON or MASTERVOLT or Equivalent:Marine Gel Service BatteriesAGM Deep Cycle Engine Start BatteriesAGM Deep Cycle Generator Start BatteriesMarine Gel Emergency Batteries Power Generator Plants:2x 40 Kw, 400VAC 50Hz Marine Diesel Generator: KOHLER or equivalentPower Management System for all 2 generators to operate automaticallySound shields will be providedNote for Generator Capacities: Generator Capacities may be increased as per Owner’s requirements and is subject to price increaseInverters & Battery Chargers: VICTRON or MASTERVOLT or equivalent:Adequate Capacity Battery Charger Groups24V DC / 230V AC / 400V AC Switchboards, Distribution Boxes & Fuses AccommodationAccommodation Lighting, Interior & Exterior:LED SpotlightsLED Spot, Emergency Lights

Exterior Putty & Paint System: AWLGRIP:Epoxy based putty on exterior surfaces above waterline with its epoxy-based primerAcrylic based final layer paint (colors owner choice)Interior Paint System: TEKNOMARIN:Epoxy based primer paint on bilge and inside of the tanks. White color paint on bilgeAntifouling Paint Under Water: AKZO-NOBEL:1 LayerZinc Anodes:1 Year Protection

Non-Fixed, Loose Interior Decoration Components:Chairs, Dishes, Fork, Knife, Linens, etc.Flag Registration Expenses & TaxesTender Boat / Rescue Boat

Delivery Time is 20 monthsBoat Shall be Delivered as Seaworthy Condition at the Free Zone’s Quay in Antalya

Built to CE Category ACommercial Classification available upon request

Gilman Yachts is the AvA appointed dealer for AvA Shipyard of Antalya, Turkey for North and South America and the outlying islands.Having finished a 110’ Kando series at the shipyard, we offer experience with the brand, the shipyard and the ownership of the yard.Projects are delivered at very favorable price FOB Antalya and built to suit the electrical requirements of the buyer.Completion time on the Kando 85 is 18-20 months from contract signing.

The BUILDER, for a period of 12 months following acceptance of the YACHT by the BUYER, undertakes to repair and rectify at its own cost and expense and free of charge to the BUYER, any defects - including latent defects or deficiencies - concerning the YACHT or parts thereof, which are caused by defective material and/or poor workmanship on the part of the BUILDER, its servants, employees or Subcontractors, but excluding defects arising after delivery due to normal wear and tear or improper handling of the YACHT or caused or aggravated by omission or improper use or maintenance of the YACHT on the part of the BUYER, its servants or agents and excluding BUYER’s Supplies.The repairs, replacements and/or rectifications shall be made at the BUILDER's yard. However, the BUYER may, after having notified the BUILDER in writing, cause the necessary repairs, replacements and/or rectifications to be carried out elsewhere provided that the BUILDER declares its consent to do so. In such case, the BUILDER shall, at its own cost, be entitled to forward necessary replacement parts or materials. The BUILDER's liability shall in such case be limited to pay the cost of repairs, including travelling and forwarding expenses, to the price of the work which the BUILDER would normally charge at its yard. In any case, the BUILDER shall co-operate with the BUYER to find proper solutions to rectify the deficiency.

The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated.
