2027 Horizon FD80

White gelcoat finishOne-piece hull and superstructure utilizingSCRIMP™ technology with Horizons patented 6D infusion, incl. longitudinal and transverse stringersHull, deck and superstructure built with licensed process SCRIMP™ for improved strength and less weightHybrid design hull bottom with sandwich construction and solid fiberglassHigh-density foam cored hull sides, decks and superstructureStringers with high-density foam coringInterior structural components all properly bonded to hullStrong collision bulkhead for extra safetyInternational brand anti-fouling bottom paint with anti-osmosis treatmentPropSpeed/PropGold metal paint for underwater appendagesTunnels for reduced draftHigh-Performance Piercing Bow (HPPB) with S/S protection platesUpper deck with bump-out design at PORT and STBD side(2) 10-person life rafts

Teak aft deck(2) ACCO 300ft high tensile 1/2” anchor chains (2) 90kg S/S anchors(2) Maxwell VWC 3500 windlass(3) Maxwell VC2500 electrical rope capstan on aft deck and bow deck(2) Chain counters in pilothouse Freshwater & seawater anchor chain washdown systemFrameless windows, slightly tinted tempered laminated Low-E glass for windshieldFrameless windows, tinted tempered laminated glass for side windowsForedeck accessed from STBD staircase/walk around on main deckForedeck built-in U-shaped seating w/ sliding tablesForedeck sun pad w/ drink holdersSunshades for bow seating, per layout(2) Bulwark side doors close to aft deck for boardingWind/weather door on each side of the aft deck leading forward to the side decksMarQuipt 7-step side boarding sea stairs43” LED electrical flip-down TV

Enclosed Skylounge with dayhead, L-shaped settee, armchair, dayhead, and custom two-level bar  (incl. 4 stools, refrigerator, ice maker, sink, glass cabinet, 43” LED electrical flip-down TV(2) manual helm chairsCustom-designed helm with full set of engine gauges, monitoring system for important equipment, fuel & water gauges, Riviera magnetic compass, surveillance camera system, bilge pump panel & navigational lightsWalk-around bridge design— PORT side bridge leads forward to bow deckNon-skid boat deckHot tub w/ bar, 3 stools, and showerHydraulic Steelhead davit ES2500 (1130kg/2,500lbs)Radar arch w/ antenna bracket(1) hidden Propane 24" BBQ with manual Hi-Lo & hidden sinkCabinets w/ refrigerator, ice maker, and storageSunshade for boat deck area, per layout

Teak beach club and swim platform; teak steps to boat deck and swim platformHydraulic door w/ pantograph door in the middleHydraulic Hi-Lo swim platform (1130kg/2,500lbs lifting capacity) with two removable corner railsSofa seating with ottomans and 43" LED TV

Twin MTU 10V2000 1,600hpSide Power SPS93/VF1650 stabilizersSide Power SH550 bow thruster and SH420 stern thrusterZipwake interceptor systemEngine load distributed through flexible mountings on S/S engine bed bonded to FRP hull girderEngine alarm system as per engine standardHigh-performance S-class 5 blade propellersBronze struts w/ backing platesShaft and Rudder packing glands with Tides Marine dripless sealsTethered remote handheld controller w/ plug on aft deck & pilot houseHypro Marine power steering systemUnderwater exhaust system for engines w/ bypass mufflersEngine room with lightweight floorHeavy-duty Insulated engine room doorS/S overhead grab rail on each side of engineAnti-noise treatment to exhaust systemDelta-T engine room demistersAir compressor

GFI protection for all AC outlets in exterior, heads, galley and engine roomElectrolysis bonding systemCathodic protection with zinc anodes for shafts, struts, etc.LED lighting system throughout interior and exterior(6) Underwater lights(2) Onan Generators 29kW (60Hz) with sound shieldPre-wired for wireless yacht controllerMaretron monitoring and control systemGlendinning shore power Cablemasters (x2) 100Amp with 75' power cable eachShore power connection with (2) 100Amp boost polarization transformers, (2) galvanic isolators, (2) 100Amp shore power plugs and (2) 100Amp bow inlets.(2) LED search lightsPre-wired for LED boat name on stern, PORT, & STBD skylounge sidesSonos stereo control by Control4 system

2,700 USG (10,220 ltrs) fuel tanks w/ sight & electrical gauges(2) Racor 500 MA fuel filters, one on each generator(2) Electric fuel transfer pumpsFuel polishing system (210GPH)1,500ltrs FRP water tank(2) 20-gal water heatersHigh-volume AC Freshwater pressure pump and backup DC pumpSpot Zero SeaXchange XTC II 1200 watermaker and Spot Zero ZTC II 2000 water purifierCharcoal filters are plumbed into the freshwater line: shore water inlet and galleyHot water circulation pumpMarine Air VARCX chilled water conditioning systemTecma toilet system100 gals holding tank & deck fitting for dockside pump-outSump pump system for grey waterElectric level indicators for holding tankHeadhunter sanitary treatment system (TW-HMX-301LP)Electric Rule Bilge PumpsHigh water level bilge alarmBilge exhaust ventilation fansFire-resistant treatment for pipe penetrationsAutomatic fire damper system(4) Portable fire extinguishersIntegrated fire alarm system in pilothouse, with CO and smoke detectors in each cabin

Guest accommodation includes:On-deck master stateroom, forward VIP stateroom, STBD VIP stateroom &  PORT VIP stateroom, all ensuitedLaundry room w/ washer/dryer, storage, ironing board, and sinkAft crew quarter w/ 2 crew cabins (one captain, one crew cabin, with one ensuite), access from STBD side SalonCustomized interior package for interior décor & lightingFull set of Wedgwood (GIO) tableware for 10, incl. dish holder, pot/pan, dishes, plates, knives, forks, glasses… etcExtra set of bed sheets for all guest cabins, including crews

3-panel manual sliding salon doorDayheadL-shaped sofa w/ table, armchair, two ottomansElectric blindsCustom area rugPORT side buffet cabinet behind sofaConvertible folding dining table & chairs, per layoutBreakfast bar design55" LED fold down TV

Enclosed galley design with Hi-Lo blindProfessional galley + extensive storage per layoutFull height Sub-Zero refrigerator + freezerMiele cooktop, range hood, oven, microwave & dishwasherSub-Zero wine cooler(1) opening porthole

King bed w/ storage drawers under, nightstands, safeSTBD chest of drawers; vanity/desk at PORT; hanging lockersEnsuite head w/sink, rain shower & toiletElectric shades(1) Opening portholes in Master head50" LED TVEscape hatch in Master w/ ladder

FWD VIP STATEROOM(2) Twin beds (with sliding function), drawer under, hanging lockers, and storageEnsuite head w/ sink, rain shower & toilet 32" LED TV MIRROR VIP STATEROOMS Queen bed w/ nightstandsEnsuite head w/ sink, rain shower & toilet 43" LED TVEscape hatch up to salon with ladder from PORT VIP stateroom

PORT Captain Cabin with double bed, hanging locker, storage, and 43” LED TVSTBD crew cabin with bunk beds, hanging lockerHead w/ sink, shower & toiletCrew area with burner, Miele washer/dryer, refrigerator/freezer, convection microwave, storageHi-Lo screen to enclose

ELECTRONICSSAT TV antenna with a symmetric dummy dome & prewire for SAT phoneReserve a cable conduit for Starlink system4G/5G Cellular router system with WiFi on board PILOTHOUSE NAVIGATIONGarmin navigational system incl.:Garmin GPS w/ Satellite compass(1) Garmin GMR™ 1236 xHD3 Open Array Radar(1) Garmin Fantom 54 Solidstate Open Array Radar(4) Garmin GPSMAP 9222 22" multifunction displaysMBB300C for inputting the Maretron info to GARMIN displayGarmin Autopilot systemGarmin Fishfinder/ Wind / Speed / Temp / Depth transducer(2) Garmin VHFGarmin AISGarmin Surround View Camera system
